Deskripsi

LIHAT BROSUR : Brosur GPS Geodetik Hi-Target V30+ Plus RTK GNSS

GPS Geodetic Hi-Target V30+ GNSS RTK yaitu suatu alat sangat dapat diandalkan untuk anda yang sedang melakukan pengukuran luas lahan dengan baik dan akurat. Karena alat ini hadir dengan teknologi yang canggih.

Kemudian, alat ini sudah menggunakan sinyal 4G untuk koneksinya yang menjadikan pengukuran anda lebih stabil dan akurat. Daya tahan baterai 5000 mAh yang menjadikan alat ini dapat bertahan lama ketika sedang pengukuran.

Fitur GPS Geodetic Hi-Target V30+ GNSS RTK

• Multi Satellite Tracking Constellition
• Fitur Dari GPS Geodetik V30 Plus
• Multi-constellation tracking
• Intelligent operation
• Diversify RTK application
• Long Life Battery
• Rugged and unique design

Spesifikasi GPS Geodetic Hi-Target V30+ GNSS RTK

• Satellite Signals Tracked Simultaneously

• • Channels: 800+
  • GPS: L1/L2/L5/L2C
  • GLONASS: L1/L2/L3
  • BDS: B1/B2/B3/B1C/B2a
  • Galileo: E1/E5 AltBOC/E5a/E5b/E6
  • SBAS: L1/L5
  • QZSS: L1/L2/L5/L6
  • NavIC (IRNSS): L5
  • Global correction service: Hi-RTP (optional)
  • Base and Rover: Interchangeable

• Positioning Performance

• • High Precision Static GNSS Surveying
    • Horizontal: 2.5 mm + 0.1 ppm RMS
    • Vertical: 3.5 mm + 0.4 ppm RMS

• • Static and Fast Static
    • Horizontal: 2.5mm + 0.5 ppm RMS
    • Vertical: 5 mm + 0.5 ppm RMS

• • Post Processing Kinematic (PPK / Stop & Go)
    • Horizontal: 8mm+1ppm RMS
    • Vertical: 15mm+1ppm RMS
    • Initialization time: Typically 10 min for base and 5 min for rover
    • Initialization reliability: Typically > 99.9%

• • Code Differential GNSS Positioning
    • Horizontal: 25cm+1ppm RMS
    • Vertical: 50cm+1ppm RMS
    • SBAS: 0.5 m(H), 0.85 m(V)

• • Network RTK
    • Horizontal: 8mm+0.5ppm RMS
    • Vertical: 15mm+0.5ppm RMS
    • Initialization time: Typically 2-10s
    • Initialization reliability: Typically > 99.9%

• • Real Time Kinematic (RTK)
    • Horizontal: 8mm+0.5ppm RMS
    • Vertical: 15mm+0.5ppm RMS

• • Hi-Fix
    • Horizontal: RTK + 10 mm/minute RMS
    • Vertical: RTK + 20 mm/minute RMS

• Communication

  • Bluetooth: 4.0/2.1 +EDR, 2.4GHz
  • Network Communication:
    • 4G cellular mobile network (TDD-LTE, FDD-LTE, WCDMA, EDGE, GPRS, GSM)
    • Wifi frequency is 2.4G, support 802.11b/g/n protocol.

• Internal UHF Radio

  • Frequency: 403-473Mhz
  • Channels: 116 (16 scalable)
  • Transmitting power: 1W/2W/4W adjustable
  • Support Multiple protocols:
    • HI-TARGET
    • TRIMTALK450S
    • TRIMMARK III
    • TRANSEOT
    • SATEL-3AS,
    • etc.
  • Working Range: Typically 3~5km, optimal 5~8km

• External UHF Radio

  • Frequency: 410~470MHz
  • Channel: 8
  • Transmitting power: 5W/25W adjustable
  • Support Multiple Protocols: TRIMTALK450S, TRIMMARK III, TRANSEOT

• Power Supply

  • Internal Battery
    • 5000mAh lithium-ion rechargeable and removable battery.
    • RTK Rover (UHF/Celullar) for 10 hours.

• • External Power
    • 6-28V DC External power input (5-pin port) with over-charge protection.
    • Power Consumption: 4.2 W

• Physical

  • Dimension (W x H): 164mm x 83.5mm
  • Weight: ≤ 1.4kg (includes battery)
  • Data storage: 8GB ROM internal storage

• Control Panel

  • Physical Button: 1
  • LED Lamp: Satellite, Signal, Power

• Environment

  • Water/Dustproof: IP67
  • Shock and Vibration: Dsurvive a 2m natural fall on to ground
  • Humidity: 100%, condensing
  • Operation Temperature: -45°C ~+ 75°C
  • Storage Temperature: -55°C ~+ 85°C

• I/O Interface

  • 1 x Mini USB Port
  • 1 x TNC antenna connector
  • 1 x DC power input (5-pin)
  • 1 x SIM card slot

• Data Formats

  • Output Rate: 1Hz-20Hz
  • Static data format: GNS, Rinex
  • Network model: VRS,  supports NTRIP protocol
  • CMR& RTCM: CMR, RTCM 2.x, RTCM 3.0, RTCM 3.2
  • Navigation Outputs ASCII: NMEA-0183

Kelengkapan :

• 1 Unit Base Configuration
• 1 Unit Rover Configuration
• 1 Unit Controller
• 1 Unit Radio External
• 1 Unit Tripod Alumunium
• 1 Unit Pole Stick

Kelebihan Beli Alat di Indosurta Cikarang :

• Garansi servis 1 tahun
• Gratis training alat
• Gratis pengiriman dan COD khusus Cikarang dsk
